D57CME31 Lead shine motor

D57CME31 Lead shine motor
Key Specifications

• Frame Size: NEMA 23 (57 mm)
• Holding Torque: 3.1 N.m (439 oz-in / 31.6 kg.cm)
• Phase Current: 4.0A for the D57CM31-4A variant (or 5.0A for the standard D57CM31)
• Step Angle: 1.8°
• Shaft Diameter: 8 mm
• Body Length: 88 mm
• Weight: 1.4 kg
• Applications & Setup
  • Common Uses: Desktop CNC routers, plasma cutters, 3D printers, and plotters.
  • Recommended Driver: Pairs well with original Leadshine stepper drivers like the DM556E.
