Part Number Breakdown

• DSBC: Festo standard profile cylinder series.
• 32: 32 mm piston bore diameter.
• 10: 10 mm stroke length (the distance the rod extends).
• 2: Usually indicates the mounting variant, suffix configuration, or generation (e.g., standard N3 series).

Core Specifications

• Standard: ISO 15552 (interchangeable with older VDMA 24562 / ISO 6431 models).
• Mode of Operation: Double-acting (air pressure moves it both forward and backward).
• Piston Diameter: 32 mm.
• Stroke Length: 10 mm.
• Piston Rod Thread: M10 x 1.25 male thread.
• Pneumatic Connection: G 1/8 inch ports.
• Operating Pressure Range: 0.6 bar to 12 bar (0.06 MPa to 1.2 MPa).
• Theoretical Force (at 6 bar): 483 N during the advance stroke.
• Ambient Temperature: -20 °C to 80 °C.

Key Features

• Cushioning Options: Available with either PPSA (self-adjusting pneumatic cushioning) or PPVA (manually adjustable cushioning) to protect the cylinder cap from high impacts.
• Position Sensing: Features built-in sensor slots on the profile body for contactless magnetic proximity sensors.
• Robust Construction: Utilizes a high-alloy steel piston rod and an aluminum profile barrel for a long service life and high rigidity.
