DAGE XD7500VR 160 KVa Open Tube X-ray System

Dage XD7500VR X-Ray Inspection System,
DAGE XD7500VR 160 KVa Open Tube X-ray System
Description:-

• Standalone
• Open Tube
• 160kV
• 70 degree Oblique view
• 1,500 X Geometric Magnification (7,000 X system magnification)
• Easy Collision-Free, High Magnification Inspection – even at oblique angle views
• Maximum Board Size / Inspection Area – 20” x 17.5” (508 x 444 mm) with no oblique views
• Maximum Inspection Area – 18” x 16” (458 x 407 mm) with oblique views
• 70° Oblique Angle Views – for any location 360° around entire inspection area
• 1.3 Mpixel Digital CCD Camera – 25 frames per second ‘real time’ image acquisition
• 20” Digital Colour Flat Panel, Wide-Screen, LCD Operator Display
• Tube:
• High Resolution
• 950nm (0.95µm) feature recognition
• Power – up to 3W
• High Magnification – 1500X geometric mag.
