DBM01/02-D19 Coupler

DBM01/02-D19 Coupler
Technical Specifications & BreakdownThe part number breaks down into key physical dimensions and specifications required for mechanical drive assemblies:

• Series (DBM01 / DBM02): Designates the specific structural design and build type of the industrial flexible coupling.
• Outer Diameter (D19): Denotes a 19 mm outer diameter.
• Application: Primarily used for motor shaft coupling, automated machine builds, and high-reliability mechanical drive systems. It provides necessary torsional stiffness while compensating for minor shaft misalignments.

AvailabilityThese industrial components are widely available through manufacturing and global retail channels:

• Direct & Replacement Options: Readily available on e-commerce platforms like  and global sourcing marketplaces like

• Alternative Equivalents: If you are building a custom setup, standard 19mm OD x 25mm length aluminum flexible shaft couplings with matching inner bore diameters (such as 5mm to 10mm options) offer similar functionality for standard automation builds.

To help find the exact replacement or alternative, could you provide:

• The required inner bore diameters for both ends of the shaft (e.g., 5mm to 8mm)?
• The total length (L) of the coupler your system requires?
• The torque or motor type (e.g., NEMA stepper motor) you are connecting it to?
