SICK DBS36E-S3EK02048 Incremental Encoder

Sick DBS36E-S3EK02048 Incremental Encoder,
Sick DBS36 Incremental Encoder DBS36E-S3EK02048

Specification/Additional Details
Brand : Sick
Encoder Type : Incremental
Shaft Diameter : 6 mm x 12 mm
Model : DBS36E-S3EK02048
Operating Voltage Range : 7 V~30 V
Initialization Time : < 3 ms
Load Current Max. : 30 mA
Pulses Per Revolution : 2,048
Shaft Material : Stainless Steel
Housing Material : Aluminum
Maximum Operating Speed : 8,000 U/min
Measuring Step : 90  Degree / electronically/pulses
Start up Torque : 0.5 Ncm (+20  DegreeC)
Mechanical Interface : Solid Shaft, Face Mount Flange
Maximum Output Frequency : 300 kHz
Operating Torque : 0.4 Ncm (+20  DegreeC)
