Desktop 3D Solder Paste Inspection System T-2010A

Off-Line Desktop High-Speed Solder Paste Inspection System T-2010A , 3D Solder Paste Inspection Equipment Desktop SPI T-2010A
Product Features
Inspection Principle : Programmable phase contour modulation measurement techniques(PSLM PMP)
Inspection type : Volume, area, height, XY offset, shape, etc.
Defect Types : shift, excessive solder, insufficient solder, offset, deformed shape, etc.

Specification/Additional Details

• Usage/Application : Solder Paste Inspection
• Accuracy : XY=10 um, Height = 0.37 um
• Product Type : Off-line 3D Solder Paste Inspection Machine
• Model : T-2010A
• PCB Size Max. (X*Y) : 460x350mm
• Inspection Speed : 1.5 SEC/FOV

• Fiducial Detection Time : 0.3sec/piece

• Maximum inspection height : +-450um (+-1200umOption)

• Barcode function with traceability : Yes

• Process control : SPC

• Smallest component : 0201
