DFM-20-100-P-A-GF Pneumatic cylinder

DFM-20-100-P-A-GF Pneumatic cylinder
Technical Specifications

• Piston Diameter (Bore): 20 mm
• Stroke Length: 100 mm
• Theoretical Force: Delivers 188 N at 6 bar pressure while advancing
• Maximum Operating Pressure: Up to 10 bar
• Operating Temperature Range: Valid operational limit between -5°C and +60°C
• Bearing Type: Plain (Slide) bearing for rigid load distribution
• Cushioning: Flexible, elastic cushioning rings at both ends to reduce impact noise and vibration
• Position Sensing: Features built-in capability for magnetic proximity sensors

Key Part Number Breakdown

• DFM: Guided drive series
• 20: Piston diameter in millimeters
• 100: Stroke distance in millimeters
• P: Elastic cushioning plates/rings on both sides
• A: Integrated profile for proximity sensing
• GF: Plain slide bearing guidance
