DFM-40-100-P-A-GF festo cylinder
Technical Specifications BreakdownThe part number string breaks down into these distinct technical properties according to the
| Part Code Feature | Value / Specification | Description |
|---|---|---|
| DFM | Guided Drive / Cylinder | Series type featuring an integrated guide |
| 40 | 40 mm | Piston/Bore diameter |
| 100 | 100 mm | Total stroke length |
| P | Elastic Cushioning | Flexible cushioning rings/plates at both ends to absorb impact and reduce noise |
| A | Position Detection | Built-in magnet designed for proximity sensors (e.g., Festo SMT or SDBT series) |
| GF | Plain Bearing | Guided structure using sturdy plain bearings for high lateral load resistance |
Performance Metrics
- Operating Pressure: 1.5 bar to 10 bar (0.15 to 1 MPa)
- Theoretical Force: 754 N on the advance stroke at an operating pressure of 6 bar
- Maximum Speed: 0.8 m/s
- Pneumatic Connection: G1/8 port threading
- Material Composition: Anodised wrought aluminium alloy housing with a high-alloy stainless steel piston rod
If you are looking to source or deploy this unit, please let me know:
- Do you need assistance finding matching proximity sensors or fittings?
- Are you looking for a CAD model or exact mounting dimensions?
- Do you require a ball-bearing guide variant (recirculating ball bearing, coded as 'KF') instead of the plain bearing ('GF')
