DK 95-35-6 motor

DK 95-35-6 motor
Technical SpecificationsThe standard operating parameters for this class of HVAC motor include:

• Rated Power: 35W to 40W
• Voltage: 220V – 240V AC
• Frequency: 50Hz / 60Hz
• Rated Speed: 800 to 900 RPM (typically running on a 6-pole configuration)
• Running Capacitor: 2.5µF to 3µF
• Shaft Diameter: 8 mm
• Insulation Rating: Class B

Variants & Rotational DirectionsWhen buying a replacement, pay close attention to the specific suffix lettering because it dictates the spin direction:

• YDK-35-6 / YDK-35-6HG: Configured for forward/anticlockwise rotation.
• YDK-35-6A H: Configured for reverse/clockwise rotation.
