LeadShine DM422C Stepper Drive

LeadShine Digital Stepper Motor Drive DM422C 2-Phase up to +40 VDC Supply voltage 0.3A to 2.2A Output current,
Leadshine 2 Phase Stepper Motor Driver DM422C

Specification/Additional Details

• Input Phase : 2-Phase
• Brand : LeadShine
• Output Current : 0.3A to 2.2A
• Input Voltage : 20 To 40V DC
• Model Name/Number : DM422C
• Usage/Application : Industrial
• Logic signal current : 7(Min.) 10(Typical) 16(Max.) mA

• Pulse input frequency : 0 to 75 kHz

• Isolation resistance : 500 Mohm
