DMSG-020 solid-state cylinder position magnetic sensor

DMSG-020  solid-state cylinder position magnetic sensor
Key Specifications

• Brand & Series: Manufactured by Airtac, belonging to the DMS Series.
• Specification Type: "G" type specification.
• Output Configuration: Two-wire digital output.
• Wiring Line: Direct outgoing line with a length of 2 meters.
• Operating Voltage: 5V to 220V AC/DC.
• Maximum Current: 300 mA.

Functionality & Replacement

• Direct Replacement: It serves as a modern replacement for the older, discontinued Airtac DS1G020 position switch.
• Purpose: Detects the presence of an internal magnet inside the cylinder to provide automated feedback on piston strokes.
• Cylinder Compatibility: Fits standard industrial series such as ACP, ACQ, TACQ, SDA, TWQ, TCL/TCM, and more.
• Durability Features: Equipped with anti-deflection wiring, making it ideal for robotic arm joints, robotic manipulators, and high-flex tank chains.
