DNC-40-25-PPV-A festo cylinder

Key SpecificationsThis model is characterized by its square profile and robust construction,
suitable for applications requiring precise linear motion.

• Piston Diameter (Bore): 40 mm.
• Stroke Length: 25 mm.
• Cushioning: PPV (Pneumatic cushioning, adjustable at both ends) to reduce impact at the end of the stroke.
• Position Sensing: The "-A" suffix indicates it is equipped for position sensing via proximity sensors (built-in magnet).
• Operating Pressure: 0.6 bar to 12 bar.
• Temperature Range: Typically operates between -20°C and +80°C (standard range).
• Piston Rod Thread: M12x1.25 male thread.
• Pneumatic Connection: G1/4 female thread.
