DP-S4V AMP100-B1 DC amplifier

DP-S4V AMP100-B1 DC amplifier
Key Specifications & Features

• Compatibility: Designed for DONGDO DP Series LVDT Displacement Transducers (e.g., DP-S4, DP-S4V, DP-10).
• Sensor Type: Supports Differential Transformer type (Full/Half bridge).
• Output Signal: DC Voltage type, typical range is 0-5V.
• Power Input: DC 24V.
• Resolution/Gain: Offers a high resolution of 1.25 mV/µm when paired with the DP-S4 sensor.
• Dimensions: 49.4 mm (W) x 53.5 mm (H) x 71.7 mm (D).
• Functionality: Features built-in gain setting switches (4 steps) and voltage-based zero/span adjustment.

Compatible Sensor: DP-S4V

• Type: Spring-push plunger electronic displacement sensor.
• Measuring Range: ±2 mm (Total 4mm).
• Repeatability: ~0.15–0.5 µm.

The AMP-100-B1 is often used for high-precision measurement tasks, such as in production line automation or quality control systems.
