DSBC-32-100-PPVA-N3 festo cylinder
Key Specifications
Piston Diameter (Bore Size): 32 mm
Stroke Length: 100 mm
Operation Mode: Double-acting
Piston Rod Thread: M10 x 1.25
Cushioning: Adjustable pneumatic cushioning at both ends (PPV)
Operating Pressure: 0.6 bar to 12 bar (0.06 MPa to 1.2 MPa)
Theoretical Force (at 6 bar advancing): 483 N
Connection Port Size: G1/8
Ambient Temperature Range: -20 °C to 80 °C
Position Detection: Yes, via proximity sensor/switch
Product Overview & Features
Compliance: Conforms to ISO 15552 standards (superseding older standards like ISO 6431 and VDMA 24562).
Design: Profile barrel construction with a magnetic piston for contactless position sensing.
Application: Suitable for general industrial automation and control tasks requiring medium-duty linear actuation.
If you're planning a purchase or installation, tell me:
- Do you need specific mounting accessories (such as clevis mountings, flange mountings, or rod eyes)?
- Are you looking for compatible proximity sensors/switches for position sensing?
I can provide the exact part numbers and recommendations for your setup.
