DSBC-40-25-PPVA-N3 Festo cylinder
DSBC-40-25-PPVA-N3 Festo cylinder
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Contact Seller :- Call or Whatsapp +91 9319902096 harshita@qysmt.in
Call or Whatsapp
+91 9319902096
Email: harshita@qysmt.in
DSBC-40-25-PPVA-N3 Festo cylinder
Part Number Breakdown
The alphanumeric code provides specific details about the configuration of the cylinder:
- DSBC: Standard-profile cylinder series designed to match the ISO 15552 standard.
- 40: Piston diameter (bore size) of 40 mm.
- 25: Stroke length of 25 mm.
- PPVA: Pneumatic cushioning that is adjustable at both ends. The "A" signifies self-adjusting cushioning capabilities that adapt optimally to load and speed changes.
- N3: Conforms to the standard profile tube layout featuring integrated sensor slots on the profile side for proximity switches.
⚙️ Core Technical Specifications
| Feature | Specification |
|---|---|
| Mode of Operation | Double-acting |
| Operating Pressure | 0.6 bar to 12 bar (0.06 MPa to 1.2 MPa) |
| Theoretical Force (Advance) | 754 N at 6 bar |
| Theoretical Force (Return) | 633 N at 6 bar |
| Piston Rod Thread | Male thread, M12x1.25 |
| Pneumatic Connection | G1/4 female thread |
| Ambient Temperature | -20°C to 80°C |
| Cushioning Length | 19 mm |
| Impact Energy at End Position | 0.7 Joules |
| Primary Structural Materials | High-alloy steel (piston rod), Die-cast coated aluminium (cover), Wrought aluminium alloy (cylinder tube), TPE-U/PU (seals) |
