DSNU-12-10-P-A FESTO AIR CYLINDER

DSNU-12-10-P-A FESTO AIR CYLINDER
Key Specifications

• Bore Diameter: 12 mm.
• Stroke: 10 mm.
• Cushioning: Features "P" cushioning, which uses elastic cushioning rings or plates at both ends to absorb impact energy (approx. 0.07 J).
• Position Sensing: Equipped with a magnet for position detection via proximity sensors (sold separately).
• Operating Pressure: Rated for 1.5 bar to 10 bar (0.15 MPa to 1 MPa).
• Force (at 6 bar):
  • Advance stroke: 67.9 N.
  • Return stroke: 50.9 N.
• Construction: High-alloy stainless steel cylinder barrel and piston rod with a wrought aluminum alloy cover for corrosion resistance.

Technical Details & Connections

• Pneumatic Port: M5 threaded connection.
• Piston Rod Thread: M6 male thread.
• Temperature Range: Operates between -20°C and +80°C.
• Mounting: Optional mounting position; can be installed using various accessories such as swivel brackets or foot mounts.
