DSNU-32-100-PPV-A AIR CYLINDER FESTO

DSNU-32-100-PPV-A AIR CYLINDER FESTO
Key Specifications

• Piston Diameter (Bore): 32 mm
• Stroke Length: 100 mm
• Mode of Operation: Double-acting (uses air pressure for both power strokes)
• Pneumatic Cushioning: Adjustable pneumatic cushioning at both ends
• Piston Rod Thread: M10x1.25
• Pneumatic Connection: G1/8
• Operating Pressure: 1 bar to 10 bar (0.1 MPa to 1 MPa)
• Theoretical Force (at 6 bar / 0.6 MPa): 482.5 N (advance) / 415 N (return)
• Ambient Temperature Range: -20 °C to 80 °C

Purchasing & Availability

• You can buy it online or view current stock status directly through industrial suppliers like
