DW-AD-509-M30-390 proximity sensor CONTRINEX
Technical Specifications

• Sensor Type: Inductive proximity sensor (Series 500 Extra Distance)
• Housing Size: M30 x 1.5 threaded barrel
• Sensing Distance: 0 to 20 mm (quasi-embeddable / quasi-flush mounting)
• Output Type: Analog (0–10 VDC or 4–20 mA proportional signal)
• Connection: Pre-wired with a 2-meter PUR cable (DW-AD variant)
• Operating Voltage: 10–30 VDC
• Switching/Response Frequency: Max. 200 Hz
• Resolution / Repeat Accuracy: 5 µm resolution with ±0.05 mm repeat accuracy
• Housing Material: Chrome-plated brass
• Protection Rating: IP67 (dust and waterproof)
• Operating Temperature: -25 °C to +70 °C
