DW-AS-624-M18-002 Contrinex sensor

DW-AS-624-M18-002 Contrinex sensor
Technical Specifications

• Sensor Type: Inductive Proximity Sensor
• Housing Size: M18 threaded barrel (18mm diameter x 63.5mm total length)
• Housing Material: Durable nickel-plated or chrome-plated brass
• Sensing Distance: 8 mm
• Mounting Style: Flush / Quasi-shielded
• Output Configuration: PNP, Normally Closed (N.C.)
• Operating Voltage: 10 to 30 V DC
• Switching Frequency: 1.5 kHz (1500 Hz)
• Electrical Connection: M12 4-pin quick-disconnect plug
• Ingress Protection: IP67 (highly dust and water-resistant)
• Operating Temperature: -25°C to +70°C
