Contrinex DW-AS-63A-C44 Inductive Proximity Sensor

The DW-AS-63A-C44 is an inductive proximity sensor manufactured by Contrinex. It is a non-embeddable sensor in a 40x40 mm cuboid housing, designed for reliable metal object detection in industrial automation.

Specifications

• Manufacturer: Contrinex
• Sensor technology: Inductive
• Housing: 40x40 mm cube, non-embeddable
• Sensing range: 40 mm (operating)
• Target object: Ferrous metals, with reduced sensing distances for other metals
• Output: PNP normally open (NO) and normally closed (NC)
• Operating voltage: 10–30 VDC
• Connection: M12 4-pin connector
• Protection rating: IP68 and IP69K, which means it can withstand high-pressure, high-temperature washdowns
• Operating temperature: –25 to +85°C
• Switching frequency: ≤ 100 Hz
• Interface: IO-Link compatible
