DZ09238B24UP  24V DC brushless axial air cooling fan
Technical Specifications

• Dimensions: 92 mm x 92 mm x 38 mm
• Operating Voltage: 24V DC
• Current Draw: 1.50 A
• Rotational Speed: Up to ~5,800 to 6,000 RPM
• Airflow: ~100 CFM
• Termination: 3-wire connection (typically supports power, ground, and tachometer/speed signal monitoring)
• Bearing Type: Dual Ball Bearing (designed for reliable, continuous 24/7 operation)
• Material: Thermoplastic PBT frame and plastic blades (UL94V-0 heat and flame resistant rating)

Common ApplicationsDue to its high airflow capability and compact 92mm square footprint, it serves as a direct replacement component for server racks, 3D printer power setups, manufacturing control panels, and desktop amplifier enclosures where dense heat dissipation is critical.Are you looking to buy a replacement for this specific fan, or do you need help troubleshooting a pinout/wiring configuration for a project?
