E2E-S05S12-WC-B1 2M Omron Sensor

E2E-S05S12-WC-B1 2M Omron Sensor

Contact Seller :- Call or Whatsapp ‪+91 9319902096 harshita@qysmt.in

Call or Whatsapp
‪+91 9319902096

Email: harshita@qysmt.in

Part Number Breakdown
  • E2E: Small-diameter proximity sensor series.
  • S05: M5 threaded cylindrical head size (\(5\text{ mm}\) outer diameter).
  • S12: Shielded housing providing a \(1.2\text{ mm}\) nominal sensing distance.
  • WC: Oil-resistant PVC pre-wired cable.
  • B1: 3-wire DC configuration with PNP Normally Open (NO) output.
  • 2M: Integrated 2-metre cable length.
Core Technical Specifications

  • Sensing Distance: \(1.2\text{ mm} \pm10\%\) (Setting range: \(0\text{ to }0.84\text{ mm}\)).
  • Standard Target Object: Iron, \(4 \times 4 \times 1\text{ mm}\).
  • Output Configuration: PNP open collector, Normally Open (NO).
  • Operating Voltage: \(10\text{ to }30\text{ VDC}\) (including \(10\%\) ripple \(p-p\)).
  • Switching Frequency: High-speed max response up to \(4\text{ kHz}\).
  • Current Consumption: Highly efficient \(10\text{ mA}\) maximum.
  • Control Output Capacity: Up to \(100\text{ mA}\) maximum load.
  • Housing Material: Robust SUS303 stainless steel barrel.
  • Dimensions: \(\text{M5} \times 25.1\text{ mm}\) overall length (\(14\text{ mm}\) thread length).
  • Environmental Protection: IP67 rated against dust and water entry.
  • Operating Temperature: Suitable from \(-25^\circ\text{C to } +70^\circ\text{C}\).
  • Status Indication: Equipped with a 360-degree layout featuring 4 high-visibility yellow LED indicators.
  • Safety Integration: Includes built-in load short-circuit and reverse polarity protection.
Key Benefits & Use Cases
  • Space Optimization: The ultra-miniature layout easily mounts directly into tight structural assemblies, robotic end-effectors, or micro-mechanisms without risking physical interference.
  • High-Speed Execution: A rapid response frequency of 4 kHz ensures reliable item tracking in fast-paced factory automation line-ups.
  • Harsh Conditions: The SUS303 stainless steel combined with an oil-resistant PVC cable withstands exposure to heavy machine vibrations, cutting oils, and coolants.
