E2E-X10D1-N Omron proximity switch sensor

E2E-X10D1-N Omron proximity switch sensor
Core Technical SpecificationsAccording to data sheets from suppliers like , the sensor features the following breakdown:

• Sensing Technology: Inductive (only detects metal targets, primarily iron/steel).
• Sensing Distance: 10 mm with a reliable setting distance range of 0 to 8 mm.
• Housing Size: M30 cylindrical threaded body made of robust nickel-plated brass.
• Mounting Style: Shielded / Flush, allowing it to be safely embedded directly into metal brackets without false triggers.
• Wiring Configuration: DC 2-Wire system requiring simpler cabling topology than 3-wire alternatives.
• Output Operation: Normally Open (NO) contact configuration.
• Voltage Compatibility: Operates within a flexible 10 to 30 VDC envelope (12–24 VDC standard).
• Switching Frequency: Up to 400 Hz for fast-moving detection on industrial production lines.

Environmental & Physical ProtectionThe sensor is explicitly hardened for high-stress automation setups:

• Ingress Protection: Rated IP67 to completely shield internals against dust ingestion and water submersion.
• Resistances: The standard pre-wired cable is wrapped in oil-resistant PVC, preventing degradation from cutting fluids or factory lubricants.
• Built-in Indicators: Features a high-visibility LED status indicator to easily confirm activation during alignment and operation.
• Circuit Protection: Includes integrated output short-circuit protection and an internal surge suppressor.
