E2E-X3D18 2M Omron sensor

E2E-X3D18 2M Omron sensor
 Key Technical Specifications

• Sensor Type: Inductive Proximity (for detecting ferrous metals)
• Size & Mounting: M8 metric thread, Quasi-flush / Quasi-shielded mounting
• Sensing Distance: 3 mm (up to 4x the range of standard M8 sensors)
• Output Configuration: DC 2-wire system, Normally Open (NO) operation mode
• Supply Voltage: 10 to 30 V DC
• Switching Current: 3 to 100 mA
• Connection Method: Pre-cabled, 2-meter oil-resistant PVC cable
• Environmental Protection: IP67, IP67G, and IP69K ratings for heavy washdown environments
• Physical Dimension: Overall barrel length of 37.8 mm
• Visual Indicator: High-luminosity 360-degree visible LED indicator

Model VariantsDepending on your environmental hazards or layout needs, you might encounter these variations:

• E2E-X3D18 2M (Standard): Features an oil-resistant PVC cable.
• E2E-X3D18-R 2M: Equipped with a highly flexible, robot/bending-resistant cable for moving components.
