Omron E2E-X7D1-M1GJ Proximity Sensor

Omron E2E-X7D1-M1GJ Proximity Sensor Cylinder type (with screw) 7mm Sensing distance Shielded DC 2-wire NO Prewired M12 smart click connector model (IEC pin arrangement) Polarity Polyurethane cable (oil resistant and reinforced) 0.3M

Specification/Additional Details

• Product Type : Proximity Sensor
• Sensing head size : M18
• Brand : Omron
• Model : E2E-X7D1-M1GJ
• Power source : DC 2-wire
• Sensing Range : 7 mm +-10%
• Setting distance : 0 to 5.6 mm
  Sensing object : Ferrous metal (Sensitivity lowers with non-ferrous metals.)
  Standard sensing object : Iron 18 x 18 x 1 mm
  supply voltage : 12 to 24 VDC ripple (p-p) 10% max.
  Operating voltage range : 10 to 30 VDC
  Control output (Switching capacity) : 3 to 100 mA
  Operation mode : NO
  Ambient Operating temperature : -25 to 70°C
  Degree of protection : IP67
