Omron E2S-Q22 Proximity Sensor

Omron E2S-Q22 Inductive Proximity Sensor 2.5mm Distance DC 2-wire NC 1M 12 to 24 VDC Supply Voltage IP67

Specification/Additional Details

• Product Type : Inductive Proximity Sensor
• Brand : Omron
• Model : E2S-Q22
• Sensing Range : 2.5 mm ±15%
• Setting Distance : 0 to 1.9 mm
• Power supply voltage : 12 to 24 VDC ripple (p-p) 10% max.
• Operating voltage range : 10 to 30 VDC

• Leakage current : 0.8 mA max.

• Control output (Switching capacity) : 3 to 50 mA

• Control output (Residual voltage) : 3 V max. (Load current 50 mA with cable length of 1 m)

• Indicator : Operation indicator (orange)

• Operation mode : NC

• Protective circuit : Power supply reverse polarity protection Surge suppressor

• Ambient temperature (Operating) : -25 to 70°C

• Degree of protection : IP67
