Omron E32-D32 Diffuse-reflective Fiber Optic Sensor Head

E32-D32 Fiber Optic Sensor Cable, Diffuse, General Purpose, E32 Series

The Omron E32-D32 is a diffuse-reflective, plastic fiber optic sensor head used for general-purpose object detection in industrial settings. It is a component of Omron's E32 Series and requires a separate fiber optic amplifier, such as models from the E3X or E3NX series, to function.

Specifications

• Sensing method: Diffuse reflective
• Sensing distance: 220 mm (with optimum settings and a suitable amplifier)
• Shape: Cylindrical axial
• Size: 2 mm diameter sensing head
• Cable length: 2 m
• Bending radius: 25 mm
• Material: Plastic core with a PVC sheath
• Operating temperature: -40 to 70°C
• Environmental protection: IP67
• Additional features: Freely cuttable cable
