E3F-DS10C4 Proximity sensor

E3F-DS10C4 Proximity sensor
Core Specifications

• Sensing Method: Diffuse Reflection (emits an infrared beam and detects the light bouncing back off the target).
• Sensing Distance: 10 cm.
• Output Type: NPN, Normally Open (NO).
• Operating Voltage: Typically \(10\text{V} - 30\text{V} \text{ DC}\) (some variations handle \(6\text{V} - 36\text{V}\)).
• Output Current: Up to 200mA or 300mA maximum load.
• Housing: Cylindrical M18 thread, usually made of PVC or steel.
• IP Rating: Commonly rated IP66/IP67 (dust and water-resistant).
• Wiring: 3-wire system (Brown: \(V_{CC}\), Blue: GND/0V, Black: Output).

Common Applications

• Conveyor belt object counting
• Automatic doors and gates
• Machine safety and alignment
• Car parking barriers and systems

For tips on how to properly wire, test, and troubleshoot this model, check out this video:
