E3JK-RR12 retro-reflective photoelectric sensor

E3JK-RR12  retro-reflective photoelectric sensor
Key Specifications

• Sensing Method: Retro-reflective with M.S.R. (Mirror Surface Rejection) function to reliably detect shiny objects.
• Sensing Range: 0.1 m to 10 m (depending on the reflector used).
• Power Supply: Wide range of 24 V to 240 V AC/DC.
• Output Type: Relay output (SPDT, 3A at 250V AC).
• Operation Mode: Selectable Light-ON / Dark-ON.
• Response Time: Max. 20 ms.
• Light Source: Red LED.
• Enclosure: Compact, cuboid ABS plastic housing with an IP64 rating.
• Connection: Pre-wired with a standard 2 m cable.
