Omron E3JK-TR12 2M Photoelectric Sensor

Omron E3JK-TR12 2M Photoelectric Sensor Through-beam 5M Sensing Distance 24 to 240V AC/DC Type Red LED (624 nm) Pre-wired Model ABS,
Omron Sensor Set E3JK-TR12 2M

Specification/Additional Details

• Sensing Mode : Through Beam
• Sensing Distance : 5M
• Brand : Omron
• Model : E3JK-TR12 2M
• Standard sensing object : Opaque: 17 mm dia. min.
• Light source : Red LED (624 nm)
• Power supply voltage : 24 to 240 VAC+-10% 50/60 Hz / 24 to 240 VDC+-10% ripple (p-p) 10% max.
• Control output : Relay output (SPDT) 250 VAC 3 A  max. 5 VDC 10 mA min.

• Operation mode : Light-ON/Dark-ON selectable

• Response time : 20 ms max.

• Sensitivity setting : Single-turn adjustment (Receiver only)

• Ambient illuminance : Incandescent lamp: 3,000 lx Sunlight: 11,000 lx

• Degree of protection : IEC: IP64

• Connection method : Pre-wired models (Cable length 2 M)
