Omron E3S-GS3E4 Groove Type Photoelectric Sensor

Omron Groove Type Photoelectric Sensor E3S- GS3E4 Through-Beam Optical Sensor 1.181" (30mm), NPN, Dark-ON/Light-ON Selectable,
Omron E3S-GS3E4 2M Grooved-Type Photoelectric Sensor Switch, 30mm Distance IR Light

Specification/Additional Details

• Sensing Mode : Through Beam
• Sensing Distance : 30mm
• Brand : Omron
• Model : E3S- GS3E4
• Standard sensing object : Opaque, 6-mm dia. min.
• Minimum detectable object : 3-mm dia. min. (black mark on transparent sheet)

• Light source (wavelength) : Infrared LED (940 nm)

• Supply voltage : 12 to 24 VDC +-10%, ripple (p-p): 10% max.

• Current consumption : 40 mA max.

• Response Time : 1ms

• Output Configuration : NPN - Dark-ON/Light-ON - Selectable

• Connection Method : Cable

• Degree of protection : IEC IP67

• Adjustment Type : Adjustable

• Operating Temperature : -25°C ~ 55°C
