Omron E3X-NA11 Fiber Amplifier

Omron Fiber Optic Amplifier E3X-NA11 Sensor Fiber Amplifier Photoelectric Sensor with Potentiometer, NPN output, Selectable Light-ON or Dark-ON mode, 12 to 24 VDC Power Supply, 2m cable, IP50.

The E3X-NA11 is suitable for a wide range of industrial automation applications, including: Object detection, Monitoring, Control systems

Features :

• Manual sensitivity adjuster: A simple, 8-turn adjuster with an indicator allows for easy manual setup.
• LED bar display: The visual bar graph provides a quick and clear indication of the light level.
• Wire-saving design: A special connector on the unit significantly reduces the amount of wiring needed, especially when connecting multiple amplifiers.
• Optical communication: This feature allows multiple E3X-NA amplifiers to be installed side-by-side without them interfering with each other.

Specification/Additional Details

• Voltage : 12-24V
• Brand : Omron
• Type : Optical Fiber Amplifier
• Light Source : Red LED
• Model Number : E3X-NA11
• Switching Output : NPN
• Housing Material : PBT
• Degree of Protection : IP50
• Setting method : Manual adjustment

• Operation mode : Dark-ON, Light-ON

• Response time : 0.2 ms

• Number of channels : 1
