Omron E3Z-D61 2M Diffuse-reflective Photoelectric Sensor

Omron Compact, Diffuse-reflective Photoelectric Sensor E3Z-D61 NPN open-collector, Light-ON/Dark-ON Selectable, 12 to 24 VDC ±10% Power supply, Polybutylene terephthalate (PBT)

The Omron E3Z-D61 is a compact, diffuse-reflective photoelectric sensor with a built-in amplifier. It is part of the E3Z series, which is known for its long sensing distance and high noise immunity in industrial environments.

Specifications

• Sensing method: Diffuse-reflective, with an integrated emitter and receiver.
• Sensing distance: 5 to 100 mm for a 100 mm x 100 mm white paper sensing object. This can be adjusted with a single-turn sensitivity adjustment knob.
• Light source: Infrared LED (860 nm).
• Output: NPN open-collector output, with both Light-ON and Dark-ON operation modes selectable.
• Power supply: 12 to 24 VDC ±10%.
• Response time: 1 ms maximum.
• Protection: IP67-rated housing for dust and water resistance, with short-circuit and reverse polarity protection.
• Operating temperature: -25°C to 55°C (-13°F to 131°F).
• Housing material: Polybutylene terephthalate (PBT).
• Indicators: Operation indicator (orange) and stability indicator (green).
• Size: The standard square housing is 31 mm (H) x 10.8 mm (W) x 20 mm (D).
• Connection: Pre-wired models are available in different cable lengths, including 0.5 m, 2 m, and 5 m.
