E3Z-LL81 OMRON SENSOR

E3Z-LL81 OMRON SENSOR
Core Specifications

• Sensing Method: Background Suppression (Diffuse-reflective)
• Sensing Distance: 20 to 300 mm
• Light Source: Red Laser (Class 1)
• Output Type: PNP Open Collector
• Operating Mode: Light-ON / Dark-ON selectable
• Response Time: 1 ms max
• Power Supply: 12 to 24 VDC
• Enclosure Rating: IP67 (dust and waterproof)
• Connection: Pre-wired (typically with a 2-meter cable)
