Omron E3Z-LS61 Photoelectric Sensor

Omron Background Suppression Photoelectric Sensor E3Z-LS61 Reflective, Diffuse Optical Sensor, 0.787inch ~ 7.874inch (20mm ~ 200mm) Sensing Distance, ADJ NPN, Dark-ON/Light-ON - Selectable

Specification/Additional Details

• Sensing Mode : Diffuse Reflective
• Sensing Distance : 0.787" ~ 7.874" (20mm ~ 200mm) ADJ
• Brand : Omron
• Model : E3Z-LS61
• Voltage - Supply : 12V ~ 24V
• Output Configuration : NPN - Dark-ON/Light-ON - Selectable

• Response Time : 1ms

• Light Source : Red LED (680nm)

• Current consumption : 30 mA max.

• Connection Method : Cable 4-wire

• IP Rating : IP67

• Operating Temperature : -25°C ~ 55°C
