E3Z-LS81-UL, E3Z-LS61-UL OMRON SENSOR
Core Specifications Comparison
| Parameter | Omron E3Z-LS61-UL 2M | Omron E3Z-LS81-UL 2M |
|---|---|---|
| Output Type | NPN Open Collector | PNP Open Collector |
| Sensing Method | Distance-settable (BGS) | Distance-settable (BGS) |
| Sensing Range | 20 to 200 mm (Max setting) | 20 to 200 mm (Max setting) |
| Supply Voltage | 12 to 24 VDC ±10% | 12 to 24 VDC ±10% |
| Load Current | 100 mA max. | 100 mA max. |
| Response Time | 1 ms max. | 1 ms max. |
| Connection | Pre-wired (2-meter cable) | Pre-wired (2-meter cable) |
| Protection Rating | IP67 | IP67 |
| Housing Material | PBT (Polybutylene Terephthalate) | PBT & denatured polyarylate |
| Operating Temp. | -25°C to +55°C | -25°C to +55°C |
Key Features
Background Suppression (BGS): Engineered to detect targets accurately regardless of workpiece color or background surface properties.
Operation Mode: Light-ON / Dark-ON selectable via a control switch.
Adjustment: Equipped with a fine-calibration sensitivity adjuster.
Indicators: Dual LED system featuring an orange operation indicator and green stability indicator.
Could you tell me whether your application requires an NPN (LS61) or PNP (LS81) output, or if you need help with wiring and setup instructions for these sensors?
