E3Z-T61(L+D) Omron Sensor

E3Z-T61(L+D) Omron Sensor
Model Code Breakdown

• E3Z: Series designation for compact
• T: Through-beam sensing method.
• 6: NPN open-collector control output.
• 1: Standard 15-meter sensing range.
• -L: Emitter sub-component.
• -D: Receiver sub-component.

Core Technical SpecificationsAccording to data sheets from the component specifications include:

• Sensing Distance: Up to 15 metres max range.
• Output Configuration: NPN open collector with Light-ON/Dark-ON selectable modes.
• Power Requirements: 12 to 24 VDC operational voltage.
• Response Time: Quick 1 ms maximum reaction speed.
• Light Source: Infrared LED emitter.
• Environmental Protection: IP67 rated PBT plastic housing, ideal for wet or dusty settings.
• Connection: 2-metre pre-wired PVC cable standard
