Omron E3ZG-D61 Photoelectric Sensor

OMRON E3ZG-D61 Photoelectric Switch Diffuse Reflective Sensor Photo Sensor NPN Light-ON/Dark-ON selectable, 2M Cable 12 To 24V DC 100mm Sensing distance, Infrared LED (860 nm), Operation indicator (orange), Stability indicator (green), IP67

Specification/Additional Details

• Sensing Mode : Diffuse Reflective
• Sensing Distance : 100 mm
• Brand : Omron
• Model : E3ZG-D61
• Supply Voltage : 12 To 24V DC

• Cable : 2M

• Product Type : Photoelectric Sensor

• Output : NPN open collector

• Operation mode : Light-ON/Dark-ON selectable

• Light source : Infrared LED (860 nm)

• Response time : 1 ms max. (Operate or reset)

• Sensitivity setting : Single-turn adjustment

• Connection method : Pre-wired models (Cable length 2 m)

• Indicator : Operation indicator (orange), Stability indicator (green)

• Degree of protection : IP67
