E3ZG-D62-S Omron sensor

E3ZG-D62-S Omron sensor
Core Specifications

• Sensing Method: Diffuse reflection
• Sensing Distance: Up to 1 meter (1000 mm) on standard 300x300mm white paper
• Output Type: NPN, Light-ON / Dark-ON selectable
• Operating Voltage: 12 - 24 V DC
• Response Time: 1 ms or less
• Enclosure Rating: IP67 (dust-tight and water-resistant for harsh environments)
• Connection: Pre-wired (typically with a 2-meter cable)

 Common Industrial Uses

• Conveyor Systems: Monitoring product flow and tracking items on a moving belt.
• Packaging & Bottling: Checking for the presence of boxes, bottles, or caps.
• Robotics & Assembly: General-purpose automated object detection.
