E40H8-2000-6-L-5 Rotary encoder

E40H8-2000-6-L-5 Rotary encoder
Quick Specifications

• Resolution: 2000 Pulses Per Revolution (P/R)
• Shaft Type: Hollow shaft with ∅ 8 mm inner diameter
• Control Output: Line Driver (enabling long-distance noise-free transmission)
• Power Supply: 5VDC ± 5%
• Max. Response Frequency: 300 kHz
• Max. Revolution: 5000 rpm
• Connection Type: Radial cable type
• IP Rating: IP50

Key Features

• Compact Design: The ∅ 40 mm housing makes it easy to install in tight, space-limited setups without additional couplings.
• High Precision: The 2000 P/R resolution provides exceptional measurement accuracy for critical industrial feedback loops.
