E5AC-RX3ASM-808 Omron Automation and Safety

E5AC-RX3ASM-808 Omron Automation and Safety
Key Technical Specifications

• Device Type: Digital Temperature / Process Controller (Simple Type).
• Dimensions: 96 mm × 96 mm (1/4 DIN standard panel cutout).
• Supply Voltage: 100 to 240 VAC.
• Main Control Output: Relay output ("R" in the part code structure).
• Auxiliary Outputs: 3 independent auxiliary/alarm outputs ("X3").
• Sampling Speed: 50 ms response time for fast, precise closed-loop adjustments.
• Display Features: High-visibility 4-digit dual row white PV display.

Common Applications

• Heater Control: Managing temperature limits in industrial ovens or kilns.
• Process Alarms: Utilizing its 3 auxiliary outputs as absolute upper/lower limit alarms to protect machinery from overheating.
• Multi-loop Systems: Executing advanced 2-PID algorithms for simultaneous heating and cooling regulation.
