E6b2-cwz1x-200 PR , E6B2-CWZ5G 200PR OMRON ENCODER

E6b2-cwz1x-200 PR , E6B2-CWZ5G 200PR OMRON ENCODER
Phase Signal Layouts

• E6B2-CWZ1X (Line Driver): Generates differential phase pairs (A/Ā, B/B̄, Z/Z̄). The complementary inverted lines cancel out electromagnetic interference over long cables.
• E6B2-CWZ5G (Push-Pull): Features active high and active low transistors in one line. It can drive both sinking (NPN) and sourcing (PNP) input modules but does not feature inverted/differential safety channels.

Wiring Codes (Standard Omron Colors)Please verify your encoder's specific printing tag before powering it on, as incorrect voltage on the 5V model will destroy the internal components
