ECMA-C10807RS delta servo motor

ECMA-C10807RS delta servo motor
Core Specifications

• Power Output: 750 W (0.75 kW)
• Rated Speed: 3000 RPM (Max. 5000 RPM)
• Rated Torque: 2.39 N⋅m
• Frame Size: 80 mm
• Encoder: 20-bit Incremental
• Voltage: 220V AC
• Weight: ~ 3 kg
• Brake / Oil Seal: No brake, with oil seal

Compatible DrivesFor optimal performance, this servo motor is typically paired with the Delta ASDA-A2 series servo drives (e.g., model ASD-A2-0721-M).
