Omron Slot-type Photomicrosensor EE-SPX303 Through-beam Sensor

Omron EE-SPX303 13mm-slot Photoelectric Switch, Omron Through Beam Photoelectric Sensor EE-SPX303N Fork Sensor, 13 mm Detection Range

The Omron EE-SPX303 is a broad-slot type photomicrosensor, a type of through-beam optical sensor. It is used in industrial automation for detecting objects that pass through its 13 mm slot. The sensor has a built-in amplifier and features enhanced resistance to electrical noise.

Specifications

• Sensor type: Transmissive/slotted interrupter
• Sensing method: Through-beam
• Sensing distance: 13 mm (slot width)
• Sensing object: Opaque object, 2.2 × 0.5 mm minimum
• Light source: GaAs infrared LED, 940 nm peak wavelength
• Control output: NPN voltage output(EE-SPX303N)
  • Voltage: 12 to 24 VDC
  • Load current: 80 mA max.
• Power supply: 12 to 24 VDC ± 10%, ripple (p-p) 5% max.
• Response frequency: 100 Hz min.
• Output mode: Dark-ON
• Indicator: Red LED for light indication
• Operating temperature: -10° to 55° C
