Omron Slot-type Photo Micro Sensor EE-SX670P

Omron Sensor EE-SX670P Photoelectric Through-beam, 5mm (slot width), PNP Output, Dark-ON and Light-ON (Selectable), 5 to 24 VDC supply voltage, PBT, IP50

The Omron EE-SX670P is a standard slot-type photomicrosensor with a PNP output, commonly used for precise object detection in automation applications. It has a 5 mm sensing distance and operates using an infrared LED.

Features and specifications

The EE-SX670P is designed for reliable and high-speed detection of small objects in tight spaces. Key features and specifications include:

• Sensing method: Through-beam with a slot.
• Sensing distance: 5 mm (slot width).
• Output type: PNP open-collector.
• Operation mode: Selectable between Dark-ON and Light-ON.
• Response frequency: As high as 1 kHz.
• Power supply voltage: 5 to 24 VDC.
• Indicator: An incident light indicator is included for easy operation monitoring.
• Connection: System connector.
• Housing material: Polybutylene phthalate (PBT).
• Protection: IP50 rating, which indicates protection from dust.
• Operating temperature: –25°C to +55°C.

Applications

The compact design and precise 5 mm slot make the EE-SX670P suitable for various industrial automation tasks, such as:

• Part detection
• Product counting
• Positioning tasks in assembly and packaging
• Use in machines like assembly robots and solder paste printers
