Omron L-shaped Slot-type Photoelectric Micro Sensor EE-SX671

Omron Sensor EE-SX671 Photoelectric Through-beam, 5 mm slot width, NPN open collector output, 5 and 24 VDC supply voltage, 4-pin connector, IP50

The Omron EE-SX671 is an L-shaped, through-beam slot-type photomicrosensor with a 5 mm sensing distance. It is a component in industrial automation and is used to detect the presence or absence of objects.

Key features

• Sensing method: Through-beam type, which detects an object that passes between its infrared LED emitter and receiver.
• Sensing distance: 5 mm slot width.
• Output type: NPN open collector output, which can be configured for either dark-on or light-on operation.
• Wide voltage range: The sensor operates on a supply voltage between 5 and 24 VDC.
• High response frequency: The response frequency is as high as 1 kHz, with a typical response time of 0.17 ms.
• Connector type: The electrical connection is made via a 4-pin connector.
• Indicator: A red light indicator provides easy monitoring of the sensor's operation.
• Compact design: The L-shaped and compact design makes it suitable for space-constrained applications.
• Protection: It has an IP50 protection rating, making it resistant to dust.
