Omron L-shaped Slotted-type Photoelectric Micro Sensor EE-SX671-WR 1M

EE-SX671-WR Omron Sensor EESX671WR, EE-SX671-WR Through-beam Photoelectric Switch Micro Sensor, Omron EE-SX671-WR Fork Sensor 5mm Range(slot width), NPN open collector output

The Omron EE-SX671-WR 1M is an L-shaped, slotted-type photoelectric micro sensor that uses a through-beam method to detect objects. It has a 5 mm slot width and an NPN open collector output that can be configured for either Light-ON or Dark-ON operation. The "1M" in the model name indicates that it has a pre-wired, 1-meter cable.

Key specifications

• Sensor type: Slotted-type photoelectric microsensor.
• Shape: L-shaped.
• Sensing method: Through-beam, which involves an emitter and a receiver in separate parts of the unit.
• Sensing distance: 5 mm slot width.
• Sensing object: Opaque objects measuring 2 x 0.8 mm or larger.
• Light source: Infrared LED with a peak wavelength of 940 nm.
• Output type: NPN open collector.
• Operation mode: Selectable Dark-ON or Light-ON.
• Connection: Pre-wired model with a 1-meter cable.
• Power supply voltage: 5 to 24 VDC, with 10% maximum ripple.
• Housing material: Polybutylene terephthalate (PBT) and polycarbonate (PC).
• Protection rating: IEC60529 standard IP50.
• Indicator: A red LED for checking operation.

Typical applications

The EE-SX671-WR 1M is designed for compact automation tasks that require precise, high-speed detection.

• Part detection: Accurately detecting the presence or absence of a small component on a production line.
• Position verification: Confirming the exact position of objects in assembly processes.
• Object counting: Counting items as they pass through the sensor slot.
• Packaging machinery: Used for positioning and monitoring within packaging equipment.
• Conveyor systems: Detecting objects on automated conveyor lines.
