Omron Slot-type Photoelectric Micro Sensor EE-SX671P
Omron Sensor EE-SX671P Through-beam, 5 mm slot, PNP Output, Dark-ON or Light-ON Selectable, 5 to 24 VDC Operating voltage, 4-pin (connector type), IP50
The Omron EE-SX671P is a slot-type photomicrosensor, also known as a slotted optical switch. It uses an infrared LED and a receiver to detect objects that pass through its 5 mm slot. This sensor is part of the EE-SX67 series and is commonly used for position detection in industrial automation.
Key specifications
| Feature | Details | |
|---|---|---|
| Sensing method | Through-beam with a 5 mm slot | |
| Shape | L-shaped | |
| Output type | PNP open collector | |
| Operation mode | Selectable for Dark-ON or Light-ON | |
| Operating voltage | 5 to 24 VDC | |
| Load current | 50 mA maximum | |
| Response frequency | 1 kHz minimum | |
| Connection method | Connector, 4-pin (connector type) or pre-wired (WR models) | |
| Indicator | Light indicator for operation monitoring | |
| Protection rating | IP50, which protects against dust ingress |
Common applications
- Assembly robots: For precise positioning and part detection.
- PCB assembly machines: Used to detect the presence or absence of components.
- High-speed applications: Its fast response time makes it suitable for automation systems requiring rapid and accurate detection.
