Omron L-shaped Photoelectric Micro Sensor EE-SX671R

Omron Sensor EE-SX671R Photoelectric Through-beam, 5mm slot width, PNP open-collector output, Dark-ON and Light-ON modes (Selectable), 5 to 24 VDC (±10%)

The Omron EE-SX671R is a compact, L-shaped photomicrosensor from the EE-SX47/67 series, used for precision object detection in industrial automation. It features a 5mm slot width and a through-beam sensing method, making it suitable for edge, part, and position detection.

Specifications

• Sensor type: Slot-type photomicrosensor
• Sensing method: Through-beam with a 5mm slot width
• Output type: PNP open-collector output
• Operation mode: Selectable Dark-ON and Light-ON modes
• Response time: 0.17 ms
• Connection method: System connector
• Power supply voltage: 5 to 24 VDC (±10%)
• Current consumption: 12 mA max
• Indicator: Red LED indicator for easy status monitoring
• Housing material: PBT and PC
• Protection rating: IP50
• Operating temperature: -25°C to 55°C
