Omron Slot-type Photo Micro Sensor EE-SX673 Through-beam Infrared Light Sensing

Omron Through Beam Photoelectric Sensor EE-SX673 Fork Sensor 5 mm Detection Range.

The Omron EE-SX673 is a compact, slot-type photoelectric sensor, also known as a photomicrosensor or optical fork sensor. It uses a through-beam sensing method to detect objects passing through its 5 mm slot. The sensor is designed for high-speed, reliable performance in embedded and industrial systems.

Specifications

• Sensing method: Through-beam with a 5 mm slot.
• Light source: Infrared LED.
• Output configuration: NPN open collector.
• Operating mode: Selectable Dark-ON/Light-ON.
• Supply voltage: 5 to 24 VDC.
• Output current: 100 mA maximum.
• Response time: 0.17 ms.
• Electrical connection: System connector.
• Operating temperature: -25 to +55°C.
• Protection rating: IP50.
• Housing material: PBT.
• Dimensions: 13.4 mm (width) x 26 mm (height) x 12.8 mm (depth).

Key features

• Easy operation monitoring: Includes a bright light indicator for easy status monitoring.
• High-speed response: A response frequency as high as 1 kHz allows for rapid detection.
• Dual operation modes: The selectable Light-ON/Dark-ON operation allows for flexibility in different applications.
• Compact size: The close-mounting, L-shaped design is suitable for installation in tight spaces.
• Output short-circuit protection: This feature helps prevent damage to the sensor.
